Bag Cleaning Machine
Model: CleanTek
The industrial FIBC cleaning machine offers a cutting-edge solution for cleaning FIBC Jumbo Bags with advanced automation and precision. Using pre-filtered air, the system efficiently removes loose contaminants before bags move to the baling press.
Each unit is equipped with a static discharger to eliminate static electricity, ensuring optimal safety and cleanliness. With top and bottom-mounted HD cameras, operators gain a real-time view of the process, guaranteeing thorough inspection, superior quality control, and consistent performance at every stage.
Enquire Now Enquire Now Enquire Now Enquire NowAdvanced Cleaning Technology: The FIBC bag cleaning machine uses pre-filtered air to remove dust and loose contaminants, delivering cleaner FIBC Jumbo Bags before baling operations.
Static-Free Operation: The machine has a built-in static discharger that eliminates static electricity during cleaning, ensuring safe handling, consistent performance, and improved overall bag cleanliness meeting the industry standards.
Real-Time Monitoring: Operators view the entire cleaning process live through the HD cameras at the top and bottom of each unit.This is to keep a check on the accuracy and reliability of the machine with each cycle.
Superior Quality Control: Each machine guarantees high cleaning precision with continuous inspection, ensuring every bag meets industry standards for hygiene, safety, and consistent quality.
Our Process: From Idea to Installation
| Parameter | Specification |
|---|---|
| Machine Dimensions (L x W) | 3400 mm x 2400 mm |
| Machine Height | 3950 mm (at lowest host level), 6350 mm (at maximum host level) |
| Customizable Height | Tailored to specific FIBC bags height needs (optional) |
| Air Blow | 3000 CFM / 12.5 HP, 2800 RPM |
| Max. Bag Body Height | 2800 mm |
| Parameter | Specification |
|---|---|
| Host | Electrically Adjustable |
| Power Consumption | 12 Kw |
| Power Supply | 415 V, 3-Phase with Neutral & Earthing, 50-60 Hz |
| Air Pressure | 6 Bar |
| Total Weight | 1500 kg (Approx.) |
Engineered for high-performance lamination, cutting, and recycling in heavy-duty tarpaulin production.
